KZJJ-1P Building Seismic Support Hanger Fatigue Testing Machine
KZJJ-1P Building Seismic Support Hanger Fatigue Testing Machine
Introduction：
Seismic supports and hangers are based on the mandatory provisions of Article 371 in General specification of seismic bracing for building GB/T 37267-2018 and GB50011-2001 Code for seismic design of buildings (2008 Edition): "Non-structural components, including building the non-structural components and the mechanical and electrical equipment attached to the building, themselves and their connection with the main body of the structure, shall be equipped with the provisions of seismic design, and the dynamic mechanical properties of the seismic support are mainly tested.
Technical parameter：
1. Test frequency range: 0.01-5Hz;
2. Amplitude 20.4kg;
3. Frequency 3Hz; sine wave
4. 1000N electric servo linear cylinder (including ±1000N load sensor, ±50mm displacement sensor): 1 set;
5. WinQuick full digital servo control system (including computer): 1 set;
6. WinQuick software system: 1 set;
7. Electrical box, wire and cable: 1 set;
8. Maximum test force: ±1000N;
9. Test force indicating value accuracy: within the range of 2%-100%FS, each point is ±1.0%;
10. Fluctuation of dynamic indicating value of test force: ± 0.5%FS;
11. The maximum displacement of the actuator: ±50mm;
12. Indicating value accuracy ±0.5%FS;
13. Main test waveforms: sine wave, square wave, triangle wave, ramp wave and sine block wave, etc.
14. Control method: displacement or test force.
15. Motor power: AC, about 0.75kW, 380V
About us:
Our company is a professional testing machine manufacturer in China. We have 13 years of production history and is well-known in China. We have our own R&D team, spare parts processing workshop, testing machine assembly workshop and professional after-sales team! We can customize tensile testing machine, pressure testing machine, bending testing machine, torsion testing machine, fatigue testing machine, fastener special testing machine, etc. Welcome friends from all over the world to visit our company and look forward to more cooperation!
Our service:
1. We guarantee that you will get higher quality and better price products from us!
2. We guarantee that we will deliver the goods for you as soon as possible!
3. Our company has a professional after-sales team, thoughtful and timely service to ensure that all users can use it without worry!
4. Our product software is upgraded for free for life, and the maintenance of minor faults is free for life!
5. We promise to reply your inquiry/email as soon as possible.
