NDT Series Drop Weight Impact Testing Machine

This drop weight impact testing machine is mainly used to measure the nil-ductility transition temperature (ndt) of ferritic steel (including sheet, section, cast steel and forged steel). The noplastic transition temperature characterizes the high temperature at which brittle fracture occurs in steels containing small cracks under dynamically loaded yield stress. The impact testing machine integrates mechanical, electrical and automatic control technologies, and realizes the fully automated process of feeding, lifting the hammer, impacting, sampling, and grasping the hammer. The drop hammer impact testing machine is equipped with multiple protection measures, which greatly improves the safety of operators and equipment. This machine is a commonly used test instrument for large and small steel mills, steel research institutes and other enterprises and scientific research units.

1. GB/T6803-2008 Drop weight test method for non-plastic transformation temperature of ferritic steel

2. ASTME208-2006 standard test method for conducting drop-weight test to determine nil-ductility transition temperature of ferritic steels

1. Drop weight impact testing machine model: uhdt-203, uhdt-303, uhdt-603

2. Large impact energy: 2000J, 3000J, 6000J

3. Small impact energy: 300J, 350J, 750J

4. Mass of sledgehammer: 70kg, 100kg, 200kg

5. The mass error of the main hammer: ±1%

6. Impact height :750mm～2915mm/750mm～3062mm/750mm～3062mm

7. The hammer lifting speed: about 7m/min

8. Height measurement resolution: 0.1mm

9. Height measurement error: ≤±10mm

10. Hammer edge hardness hrc:58～62

11. Hammer blade curvature radius r:25±0.1mm

12, bearing hardness hrc:58～62 13,

13. The radius of curvature of the support :r15±0.1mm, r20±0.1mm

14. The deviation between the center of the hammer blade and the center of the support: ≤±2.5mm

15. The span of the sample support: 305mm and 100mm

16. Specimen size: 360×90×25mm, 130×50×20mm, 130×50×16mm

17. Mainframe power supply: three-phase five-wire 380v10a

18. Air source requirement: 0.4～0.7mpa

1. It has the functions of automatic sample feeding and automatic positioning, which is easy to operate and has high work efficiency.

2. The drop-weight test frame adopts a frame structure with 4 columns connecting the bottom plate and the top plate. The bottom plate is made of integral solid steel plate, which fully guarantees the stability of the testing machine during impact.

3. The hammer body is made of high-strength integral steel plate with high impact resistance.

4. The self-locking device of the gripping hammer will lock itself after the hammer is grasped. There will be no accident under the action of gravity, and it will not be opened when the power is unexpectedly turned off, and the safety is high.

5. The testing machine has a fully enclosed protective net and multiple safety protection devices to fully ensure the safety of the testing personnel.

6. The anvil replacement tool is simple and convenient to replace.

7. The intelligent control system alarms the faults, such as: the sample is not in place, the hammer head is not self-locking, the protective device is not closed, the hammer head is not lifted in place, etc.

8. It adopts Siemens programmable controller equipped with touch screen control, with high reliability, strong anti-interference ability, versatility, adaptability, strong expansibility, and small maintenance workload.

1. Thirteen years of experience in the production of test equipment, China’s high-tech enterprises, and guaranteed product quality!

2. Our company has a high-level R&D team composed of more than ten people, who can customize various test equipment at the fastest speed according to your needs and and the product technology is advanced!

3. The company has its own machining workshop and installation workshop, advanced machining equipment, skilled operating technicians, and strict testing procedures. Therefore, the delivery is timely and the quality is guaranteed!

4. Our products are all over the world and have a good reputation!
