500N Spring Fatigue Testing Machine

TLS-PL10 mechanical spring fatigue testing machine is mainly used for fatigue life test of various coil springs and barrel shock absorbers used in various automobiles, motorcycles, and other motor vehicles.

Send Inquiry

Product Introduction

TLS-PL10 500N Spring Fatigue Testing machine

Purpose

Skills requirement

Resistance test range: 0-10KN

The test amplitude of the specimen: ±100mm (that is, the stroke is 350mm), adjustable

Specimen test frequency: ≤5Hz (the greater the stroke, the lower the frequency

100-200 frequency ≤3Hz

50-100 Frequency≤5 Hz

0-50 frequency≤8 Hz) adjustable

Specimen test space: ≤150mm; adjustable

Movement direction of the specimen: vertical direction

Preset number of trials: 9×10⁹times

Stations: 16

Stepless speed regulating motor:1

Space adjustment motor: 1

Control system:1 set

The maximum outer diameter of the spring: Φ25mm

Features

The TLS-PL10 mechanical spring fatigue testing machine consists of a main engine and a strong electric control box.

(1) According to the technical requirements of the spring, the amplitude and frequency of the spring can be adjusted freely.

(2) The preset number of tests will automatically stop.

(3) Simple operation, reliable and stable operation.

(4) It has the function of breaking the spring to stop (no preload).

Configuration of the testing machine

One host;

One speed regulating motor

A set of control system

One space adjustment motor

About us:

Our company is a professional testing machine manufacturer in China. We have 13 years of production history and is well-known in China. We have our own R&D team, spare parts processing workshop, testing machine assembly workshop and professional after-sales team! We can customize tensile testing machine, pressure testing machine, bending testing machine, torsion testing machine, fatigue testing machine, fastener special testing machine, etc. Welcome friends from all over the world to visit our company and look forward to more cooperation!
