Portable Vickers Hardness Tester

Overview:

HV-30 Vickers hardness tester is suitable for measuring the Vickers hardness of tiny, thin, ssurface-permeated specimens and the Knoop hardness of glass, ceramics, agate, artificial gems and other brittle and hard materials. It is an ideal hardness testing instrument for research and testing by scientific research institutions, enterprises and quality inspection departments.



Technical parameter :

Technical parameter
Model	HV-30
Test force	1.0Kgf(9.8N)
	3.0Kgf(29.4N)
	5.0Kgf(49.0N)
	10Kgf(98.0N)
	20Kgf(196N)
	30Kgf(294N)
Hardness test range	5HV~3000HV
Objective lens	10×，20×
Total magnification	100×，200×
Measuring range	400μm
Indexing value	0.1μm
Test force application method	Automatic loading and unloading test force
Turret method	Manual turret
Test force holding time	0～60s (one unit per second, any input)
Maximum height of specimen	200mm
The distance from the center of the indenter to the outer wall	130mm
Voltage	AC220V/50Hz
Dimensions	620*330*640mm
Weight	About 70Kg
