Testing Machine for Clamping Performance Of Rubber Sealing Tape
NKSSFL-05 Testing machine for clamping performance of rubber sealing tape
This testing machine is designed according to the relevant requirements of the China Transportation Industry Standard JT/T327-2016 Highway Bridge Telescopic Device, and is mainly used for the test method of the clamping performance of the rubber sealing belt, and performs reciprocating stretching, holding, and other tests. Other measuring devices can be added to meet the standard requirements of different test methods.
Technical standard
|
Item index model |
NKSSFL-05 |
|
Maximum test force |
500n |
|
Host structure |
Horizontal single space model |
|
Testing machine level |
Level 1 |
|
Effective measuring range of test force |
0.2%-100%f·s（0.4%-100%f·s） |
|
Relative error of test force indication |
±0.5%(±1%) |
|
Test resolution |
500000 yards (the whole process is not divided into files) |
|
Deformation measurement range |
1%-100%f·s |
|
Deformation indication relative error |
±0.5% |
|
Deformation resolution |
500000 yards (the whole process is not divided into files) |
|
Displacement rate control adjustment range |
0.001-200mm/min |
|
Effective stretching space (without fixture) (mm) |
400 |
|
Effective test width (mm) |
200 |
|
Host size (mm) |
800*350*230 |
|
Power supply |
Ac220v 50hz 400w |
|
Weight |
27kg |
