LEEB130 Leeb Hardness Tester
LEEB130 Leeb hardness tester
Product introduction:
Based on the Leeb hardness measurement principle, the hardness tester can detect a variety of metal materials, and the measured values are accurate and stable. It displays the hardness measurement value and can be easily converted between different hardness scales. The hardness tester can preset the tolerance limit, and automatically alarm when it exceeds the range, which is convenient for users to test in batches. It can be equipped with 8 different impact devices, automatically recognizes the type of impact device, and does not need to be recalibrated when replacing. It is with large-screen LCD display, menu-based operation, rich and intuitive information.
Main function:
●According to the Leeb hardness measurement principle, a variety of metal materials can be tested, and the measured values are accurate and stable;
● It display the hardness measurement value, and can easily switch between different hardness scales;
● Tolerance limit can be set in advance, out of range automatic alarm, which is convenient for users to test in batches;
● It can be equipped with 8 different impact devices, the type of impact device is automatically recognized, and there is no need to recalibrate when replacing;
● Large-screen LCD display, menu-based operation, rich and intuitive information;
● High-brightness LED backlight, easy to use in dim light environment;
● Built-in high-speed thermal printer, on-site real-time printing of measurement data;
● Low power consumption design: automatic sleep, automatic shutdown and other energy-saving functions;
● Closed metal shell;
● Built-in battery power supply, standby time of 150 hours, suitable for field work;
Applicable materials:
Steel and cast steel, alloy tool steel, stainless steel, grey cast iron, ductile iron, cast aluminium alloy, copper-zinc alloy (brass), copper-tin alloy (bronze), pure copper, forged steel.
Technical parameter :
|
Project name |
Leeb130 |
|
Measuring range |
100 ~ 990HLD |
|
Indication error/repeatability |
±6HLD（HLD=760）/ 6HLD（HLD=760） |
|
Storage |
600 groups |
|
Recognizable impact device |
D、G、C、DL、DC、D+15、DS |
|
Impact device socket |
LEMO socket |
|
Measurement direction |
360° |
|
Hardness scale |
HL、HB、HRC、HRB、HV、HS |
|
PC communication |
Have |
|
Power supply |
2 AA alkaline batteries |
|
Operating hours |
100 hours |
|
Shell material |
Metal shell |
|
Dimensions |
130*70*25 mm |
|
Weight |
450g |
|
The standard configuration |
Host, D-type impact device, standard test block, small support ring, nylon brush, battery |
|
Optional |
Special-shaped support ring, impact device, standard test block, communication software, computer |
Our Commitment：
1. We are a test equipment manufacturer!
2. We have a R & D design team to ensure that you get higher product quality and better prices!
3. We have our own parts processing workshop and product installation workshop, so we guarantee delivery for you as soon as possible!
4. Our company has a professional after-sales team, thoughtful and timely service, to ensure that all users have no worries!
5. Our product software upgrade is free for life, small fault maintenance is free for life!
6. We promise to reply to your inquiry/email as soon as possible.
