LEEB110 Leeb Hardness Tester
LEEB110 Leeb hardness tester
Product introduction:
The Leeb110 hardness tester is a multifunctional hardness measuring instrument. It uses Chinese display, menu operation, simple and convenient operation. The machine can directly display various hardness values such as Leeb Brinell, Rockwell, Vickers, Shore, etc. The instrument is small and portable, suitable for harsh operating environments and resistant to vibration, shock and electromagnetic interference.
Product Features:
1. Equipped with D-type impact device.
2. Menu operation, rich information and intuitive.
3. High-brightness LED backlight is convenient for use in dimly lit environments.
4. Automatic sleep, automatic shutdown and other energy-saving functions, low-power design.
5. Powered by ordinary batteries. The standby time is 100 hours, and it is easy to carry and suitable for field operations.
Scope of application:
1. Installed mechanical or assembly parts.
2. Mold cavity.
3. Heavy workpieces.
4. Failure analysis of pressure vessels, steam turbine generator sets and their equipment.
5. The measurement space is very narrow for workpieces.
6. Bearings and other parts.
7. Material distinction of metal material warehouse.
8. Inspection of multiple measurement parts in a large range of large workpieces.
Technical parameter:
|
Project name |
Leeb110 |
|
Measuring range |
100 ~ 990HLD |
|
Indication error/repeatability |
±6HLD（HLD=760）/ 6HLD（HLD=760） |
|
Storage |
600 groups |
|
Recognizable impact device |
Type D non-pluggable |
|
Impact device socket |
/ |
|
Measurement direction |
360° |
|
Hardness scale |
HL, HB, HRC, HRB, HV, HS |
|
PC communication |
none |
|
Power supply |
2 AAA alkaline batteries |
|
Operating hours |
100 hours |
|
Shell material |
Plastic shell |
|
Dimensions |
129*68*25mm |
|
Weight |
230g |
|
The standard configuration |
Host, D-type impact device, standard test block, small support ring, nylon brush, battery |
|
Optional |
Special-shaped support ring, impact device, standard test block, communication software, computer |
